4 x HDMI Input to HDMI Arc, 5.1CH Dolby PDIF and 2.1 L&R Stereo

Microware HDMI2.0 Switch 4×1 HDMI Audio Extractor 4K x 2K @ 60Hz with Toslink+L/R Stereo Audio up to 7.1CH 192khz SPDIF RCA HDCP 2.2

• HDMI ARC Adapter – Extractor the Audio from the TV to Soundbar or Amplifier. Connect your TV HDMI(ARC) Port to this switch HDMI Output Port with HDMI Cable, then optical cable/ L/R or 3.5mm headphone to the soundbar, Speaker, home theater, A/V receivers, etc.
• HDMI Audio Extractor – with Optical TOSLINK SPDIF + L/R audio out allow you to extract the sound from the HDMI input source (like PS4, Xbox One, etc.) to your soundbar or amplifier no need to connect TV or Monitor.
• HDMI 2.0 Switcher – Supports up to 4K @60Hz (420/422/444), 3D, Color & Deep Color; Supports 7.1/5.1/2.1 Ch., Dolby Digital, DTS-HD and Dolby TrueHD audio; Support max bandwidth up to 18Gbps.
• Wide Applicability: Compatible with any HDMI devices such as Nintendo Switch, PS4 Pro, Xbox 360, Xbox One X, PS3, Beamer, DVB Receivers, Blu-ray Player, Apple TV 4, Laptop and HDTV/HD Monitor, etc.

Microware HDMI2.0 HDCP2.2 HDMI 4×1 Switch & Audio Extractor 4 ports HDMI switcher 4 input 1 output HDMI selector
4 Port HDMI Switch & Audio Extractor SPDIF/RCA stereo outputs with Ultra HD 4K ARC EDID setting allows you to connect four HDMI inputs to one HDMI output. It also allows you to connect to a 7.1 channel digital surround on HDMI output or 5.1 channel digital surround sound on the Toslink digital output or 2.0 channel PCM audio on the RCA stereo output.

Features:

• Input: HDMI x 4.
• Output: HDMI x 1, Toslink / SPDIF x 1, Stereo RCA x 1.
• Supports Ultra HD 4Kx2K @60Hz.
• Supports Full HD.
• Supports 3D.
• Supports HDMI2.0, HDCP2.2
• Supports 12-bit Deep Color per channel, maximum of 36-bit for all channels.
• Supports 6.0Gbps TMDS/600MHz pixel clock rate per channel, maximum total TMDS throughput is 18Gbps.
• Supports uncompressed audio such as LPCM.
• Supports compressed audio such as DTS Digital, Dolby Digital, DTS-HD, and Dolby TrueHD.
• Supports HDMI pass-through.
• Supports up to 7.1CH digital surround on HDMI output.
• Supports up to 5.1CH digital surround on Toslink output.
• Supports up to 2.0 channel analog stereo on Stereo output.
• Supports Standard Audio, DSD Audio, and HD (HBR) Audio.
• Supports ARC(Audio Return Channel).

Specification:

1. Input: HDMI x 4.
2. Output: HDMI x 1, Toslink / SPDIF x 1, Stereo RCA x 1.
3. HDMI resolution: Ultra HD 4K2K@60Hz max; 3D 1080p/24 max
4. Support video color format: 36-bit Deep Color al l channels maximum
5. Audio output: HDMI pass-through; Up to 7.1 CH; Toslink output up to 5.1 ch;RCA L/R output stereo audio
6. Max bandwidth per channel: 600MHz
7. Max baud rate per display: 18 Gbps
8. Input/Output TMDS signal: 0.5~1.5V
9. Input cable distance: ≤50ft/15m 24 AWG HDMI high-speed Cable at1080P@24bit 60Hz
10. Output cable distance: ≤50ft/15m 24 AWG HDMI high-speed Cable at1080P@24bit 60Hz
