HD815 HDMI ARC to 5.1 Channel RCA Converter/Hard Decoder

If you are planning to make digital home theater at home, then this is an important digital audio Decoder for you. You can check its specifications and see if it is suitable for you. This digital audio decoder supports DTS, Dolby Digital (AC3), LPCM, and PCM formats. The USB Sound card supports WinXP and Win7. Window 8, Window 10, and other system source codes.

𝐀𝐔𝐃𝐈𝐎 𝐃𝐄𝐂𝐎𝐃𝐄𝐑 (DAC) –
Digital Audio Converter Not Only Supports AC-3/ DTS/ LPCM/ PCM/ RAW But Also Can Decode Dolly AC-3/ DTS Digital Audio to Analog Audio.

𝟓.𝟏𝐂𝐇 𝐃𝐈𝐆𝐈𝐓𝐀𝐋 𝐀𝐔𝐃𝐈𝐎 –
This audio decoder can auto-convert HDMI input to 5.1 channel analog audio output, Auto decode AC-3/DTS (LPCM/PCM/RAW) input signal without any action.

𝐕𝐎𝐋𝐔𝐌𝐄 𝐀𝐃𝐉𝐔𝐒𝐓𝐀𝐁𝐋𝐄 –
With Volume Knob to Adjust Volume, Allowing You to Adjust The Output Volume. Noise Can Be Eliminated When NO Signals are Input And Automatically Mute While Non-audio Signals Input.

[32KHz to 𝟏𝟗𝟐𝐊𝐇𝐙;]- Supports Sampling Rate at 32 KHz, 44.1 KHz, 48 KHz, 96 KHz, and Even 192 KHz(Many Others Just Support up to 96 KHz), Providing High Sound Quality. It Also Supports 24-bit SPDIF Incoming Bit Stream on Left and Right Channels.

𝐖𝐈𝐃𝐄 𝐂𝐎𝐌𝐏𝐀𝐓𝐈𝐁𝐈𝐋𝐈𝐓𝐘 –
With SPDIF/ Coaxial Input And 2.0/ 5.1CH RCA + 3.5MM Audio Output, Suitable for Blu-ray, DVD, PS3, PS4, HDTV, Etc. (NOTE: The RCA Output Should Be Connected to the Amplifier First But Not Be Connected to the Speaker Directly.)

5.1ch audio decoder is used to decode HDMI-Compatible, optical, coaxial, pc-USB, USB, Bluetooth, and other audio into 5.1 independent channel output (6 channels) or 2.0 output, and then output surround sound by power amplifier or active speaker.

Support one HDMI input, one Coaxial input, one Optical input, one PC-USB input, one AUX input, and one USB 2.0 input. You can switch different signal sources randomly via Button or Remote

Support one HDMI(ARC) output, one Optical output, one Coaxial output, and one 5.1ch analog audio output of RCA, all audio outputs simultaneously

Please use a 19-core standard HDMI cable

All signal source(HDMI/ARC/COAXIAL/OPTICAL/PC-USB/USB) can decode to 5.1ch output, it is audio decoder system

Support Bluetooth 5.0 audio receiver

HDMI resolution up to 4Kx2K@30hz, support 3D

Supported audio format: DTS HD/DTS/DTS-ES/Dolby Atmos/ AC3/WAV/FLAC/APE/HDCD/AAC/WMV/MP3/M4A etc.

Support 5.1ch/2.0ch output mode, FL/FR active when 2.0ch output mode

Support Button or IR remote switch input source

Supporting IR adjust VOLUME

The power-off memory function automatically switches to the last used signal channel, USB broadcast memory before the power-off.

The use of DC 12V/1A external power adapter power supply, the wide voltage can use DC (5-19V) power supply

USB has powerful decoding and playback cape abilities, almost all common audio formats are compatible with ape, flac, dts, dts-es, ac3, wav, mp3, etc., but can not play video formats. U disk playback supports previous/next/single loop / all loop and other operations.

𝐏𝐚𝐜𝐤𝐚𝐠𝐞 𝐈𝐧𝐜𝐥𝐮𝐝𝐞𝐝 𝐈𝐧 –
1x Audio Converter Decoder
1x Remote Control
1x Optical Cable
1x Power Adapter

You can also check HD951B HDMI to 5.1CH Digital Audio Decoder with Display.

FAQs –

What is Dolby Hard-Decoding?

Dolby Hard-Decoding” refers to the process of decoding audio signals encoded in Dolby formats using dedicated hardware, typically found in audio playback devices such as receivers, soundbars, and home theater systems. This enables smooth and high-quality audio playback, allowing users to enjoy the intended audio experience of Dolby-encoded content.

To alleviate the burden on the main processor or CPU, many audio devices incorporate specialized hardware decoders specifically designed to handle Dolby audio formats
